Product Details:
Payment & Shipping Terms:
|
Product Name: | 201 Fire-proof Self-lock Stainless Steel Cable Ties- Ball-Lock Ties | Color: | Naked |
---|---|---|---|
Length: | All Length Are Avaliable | Applications: | Shipbuilding Industry,Oil Pipeline,Power Industry,communications |
Product Material: | Stainless Steel | Width: | 7.9mm |
Flammability: | Fireproof | Material: | 304,316,201 |
MOQ: | 1000pcs | Type: | Self-locking |
Pack: | 100pcs/bag | ||
Highlight: | metal cable ties,self locking stainless steel cable ties |
201 Fire-proof self-lock Stainless Steel Cable Ties- Ball-Lock Ties
Product Feature
Uncoated version, for high temperature applications and high tensile strength,Easy install.
Tongue Head Design makes the inside surface smooth, won't hurt the bundled objects.
Applications:
Scope Of Application: able ties are widely used in banding internal connecting wires such as television, computer, lighting, electrical, electronic toys and other products; fixing mechanical equipment, oil pipe and cable lines on ships; bicycle vehicle packaging or other objects bundling, and also used in agriculture, horticulture, handicrafts and so on.
Description
1 ,these stainless steel cable ties work almost identically to plastic ties; the difference is that the metal ties use a ball bearing to lock the tie in place, and longer life than plastic ties.
2 ,An upside is that one doesn't have to worry about the tie melting in a high temperature setting. Another upside is that you can bind to a much higher load than with (similarly-sized) plastic ties
3 ,you can use a pliers to pull and set (and fold over a small length to act as a lock), but to get best results you might find yourself needing a specialty tool such as our Stainless Steel Cable Tie Tool HS-600
Part No. | Approx. length. mm(inch) |
Approx. width mm(inch) |
Thickness mm |
Max. Bundle Dia. mm(inch) |
Min.loop tensile strength N(lbs) |
Pcs/Bag |
JHCN-4.6 x 150 | 150(5.9) | 4.6(0.181) | 0.25 | 37(1.46) | 600(135) | 100 |
JHCN-4.6 x 200 | 200(7.87) | 50(1.97) | ||||
JHCN-4.6 x 250 | 250(9.84) | 63(2.48) | ||||
JHCN-4.6 x 300 | 300(11.8) | 76(2.99) | ||||
JHCN-4.6 x 350 | 350(13.78) | 89(3.5) | ||||
JHCN-4.6 x 400 | 400(15.75) | 102(4.02) | ||||
JHCN-4.6 x 450 | 450(17.72) | 115(4.53) | ||||
JHCN-4.6 x 500 | 500(19.69) | 128(5.04) | ||||
JHCN-4.6 x 550 | 550(21.65) | 141(5.55) | ||||
JHCN-4.6 x 600 | 600(23.62) | 154(6.06) | ||||
JHCN-7.9 x 150 | 150(5.9) | 7.9(0.311) | 0.25 | 37(1.46) | 800(180) | 100 |
JHCN-7.9 x 200 | 200(7.87) | 50(1.97) | ||||
JHCN-7.9 x 250 | 250(9.84) | 63(2.48) | ||||
JHCN-7.9 x 300 | 300(11.8) | 76(2.99) | ||||
JHCN-7.9 x 350 | 350(13.78) | 89(3.5) | ||||
JHCN-7.9 x 400 | 400(15.75) | 102(4.02) | ||||
JHCN-7.9 x 450 | 450(17.72) | 115(4.53) | ||||
JHCN-7.9 x 500 | 500(19.69) | 128(5.04) | ||||
JHCN-7.9 x 550 | 550(21.65) | 141(5.55) | ||||
JHCN-7.9 x 600 | 600(23.62) | 154(6.06) | ||||
JHCN-7.9 x 650 | 650(25.59) | 167(6.57) | ||||
JHCN-7.9 x 700 | 700(27.56) | 180(7.09) | ||||
JHCN-7.9 x 750 | 750(29.53) | 191(7.52) | ||||
JHCN-7.9 x 800 | 800(31.5) | 193(7.59) | ||||
JHCN-12 x 150 | 150(5.9) | 12(0.472) | 0.25 | 37(1.46) | 1200(270) | 100 |
JHCN-12 x 200 | 200(7.87) | 50(1.97) | ||||
JHCN-12 x 250 | 250(9.84) | 63(2.48) | ||||
JHCN-12 x 300 | 300(11.8) | 76(2.99) | ||||
JHCN-12 x 350 | 350(13.78) | 89(3.5) | ||||
JHCN-12 x 400 | 400(15.75) | 102(4.02) | ||||
JHCN-12 x 450 | 450(17.72) | 115(4.53) | ||||
JHCN-12 x 500 | 500(19.69) | 128(5.04) | ||||
JHCN-12 x 550 | 550(21.65) | 141(5.55) | ||||
JHCN-12 x 600 | 600(23.62) | 154(6.06) | ||||
JHCN-12 x 650 | 650(25.59) | 167(6.57) | ||||
JHCN-12 x 700 | 700(27.56) | 180(7.09) | ||||
JHCN-15 x 200 | 200(7.87) | 15(0.59) | 0.4 | 50(1.97) | 1500(337) | 100 |
JHCN-15 x 250 | 250(9.84) | 63(2.48) | ||||
JHCN-15 x 300 | 300(11.8) | 76(2.99) | ||||
JHCN-15 x 350 | 350(13.78) | 89(3.5) | ||||
JHCN-15 x 400 | 400(15.75) | 102(4.02) | ||||
JHCN-15 x 450 | 450(17.72) | 115(4.53) | ||||
JHCN-15 x 500 | 500(19.69) | 128(5.04) | ||||
JHCN-15 x 550 | 550(21.65) | 141(5.55) | ||||
JHCN-15 x 600 | 600(23.62) | 154(6.06) | ||||
JHCN-15 x 650 | 650(25.59) | 167(6.57) | ||||
JHCN-15 x 700 | 700(27.56) | 180(7.09) | ||||
JHCN-15 x 750 | 750(29.53) | 191(7.52) | ||||
JHCN-15 x 800 | 800(31.5) | 193(7.59) | ||||
JHCN-15 x 1000 | 1000(39.37) | 206(8.11) |
